C-200 Commercial/Industrial RO Controller

The Crystal Quest C-200 Microprocessor Controller is a versatile controller for reverse osmosis systems that offer advanced features and options which make it an exceptional choice for large commercial and industrial reverse osmosis systems.

The Crystal Quest C-200 Controller has the flexibility to meet many specifications with six (6) switch inputs, five (5) analog inputs, six (6) relay outputs, and two (2) TDS/conductivity inputs. The 4 line by 20 character LCD display provides sensor readings, hours of operation, temperature, alarms, and operating status of the RO system.

Features:

Universal AC power 80-265 VAC 50/60Hz
4-line x 40-character backlit LCD
18-key keypad with integral alarm light
Programmable time delays and set points
Real-time clock with battery backup
Non-volatile set-point memory
Audible alarm with timed alarm silence
English or metric readings
Input/output indicator LEDs
Preprogrammed RO functions

###

Specifications:

Power: 80-265VAC, 50/60Hz
Enclosure: 14”x12”x8” NEMA 4X (larger enclosures are required to accept motor starters)

Functions:

Feedwater valve relay
RO and auxiliary pump control relays
Permeate and feed TDS/Conductivity
Membrane flush valve relay
Permeate divert valve relay
Temperature
Operating hours
Low feed pressure switch
High pump pressure switch
Pretreatment lockout
Flowmeter interface for permeate
RO storage tank switches (1 or 2)
RO storage tank low switch
Remote alarm output

Inputs:

Six (6) switch
Five (5) 4-20mA analog
Two (2) Conductivity/Resistivity
One (1) pH
One (1) ORP
Four (4) flow

Outputs:

Six (6) relay
One (1) 4-20mA analog

Communications:

RS-232
Modem
RS-485
Graphical display

###

Optional Accessories:

pH, ORP sensor with display and alarm set points
IEC motor starters and control transformers
Flow sensors to display flow in GPM or LPM, with % recovery displayed and alarm setpoints for high and low flow rates
Pressure sensors allowing display on LCD of pressures and differential pressures with programmable setpoints for high, low, and differential pressure alarms

###
